Specifications for
MPG A1000GS PCIE5
WEIGHT (CARD)
WEIGHT (CARD)
169g
Efficiency Rating
Efficiency Rating
80 PLUS Gold (up to 90%)
Modular
Modular
Yes (full modular)
Fan Size
Fan Size
135 mm
Fan Bearing
Fan Bearing
Fluid Dynamic Bearing
Dimensions (DxWxH)
Dimensions (DxWxH)
150 x 150 x 86 mm
PFC Type
PFC Type
Active PFC
Input Voltage Range
Input Voltage Range
100-240V~
Power Watt
Power Watt
1000W
Power Excursion
Power Excursion
2350W (*up to 235% of the PSU's rated power for 100μs)
Input Frequency Range
Input Frequency Range
50-60 Hz
Protection
Protection
OCP/ OTP/ OPP/ SCP/ OVP/ UVP/ SIP/ NLO
ATX (24 pin)
ATX (24 pin)
1
EPS (4+4 pin)
EPS (4+4 pin)
2
PCI-E (6+2 pin)
PCI-E (6+2 pin)
1
SATA (15 pin)
SATA (15 pin)
8
MOLEX (4 pin)
MOLEX (4 pin)
4
Dimensions
Dimensions
120mm x 120mm x 25.6mm
Connector
Connector
4-Pin PWM/DC
PCI-E 5.1 (16 pin)
PCI-E 5.1 (16 pin)
2 (600W)
